3732 fiberglass fabric|3732 fabric|Fiberglass fabric 3732|Fiberglass manufactory |
|
|
 |
[Views：
]  |
| |
| |
Yarn Type：
C-glass Grade：A Application: Fireproof, high temperature resistance ,heat preservation,pipeline warpping and so on.
|
Item No.
|
3732 |
|
Weave
|
Twill |
|
Yarn(tex)
|
Warp
Weft |
EC9 33 2×2
EC9 33 2×2
|
ECG 150 2/2
ECG 150 2/2 |
|
Width
|
101.6±2cm
121.9±2cm
152.4±2.54cm
|
40±0.75 inch
48±0.75 inch
60±1 inch
|
|
Thickness |
0.43±0.043mm
|
0.0133±0.0067inch |
|
Weight
|
1700±85g/㎡ |
50±2.5oz/yd2 |
|
Thread
Count |
Warp
Weft |
18±1.8per cm
13±1.3per cm |
45.7±4.5per inch
33±3.3per inch |
|
Tensile
strength
|
Warp
Weft |
11000 N/5cm
8500 N/5cm |
1222Ibs/inch
944Ibs/inch |
|
L.O.I% |
＜0．5% |
|
Service Temperature |
550℃ |
 |
|
|
|
|
