FW600 fiberglass fabric|Fiberglass fabric FW600|Fiberglass manufactory |
|
|
 |
[Views：
]  |
| |
| |
|
Item No.
|
FW600 |
|
Weave
|
Plain |
|
Yarn(tex) |
Warp
Weft |
EC9 33 3×2
EC9 33 3×2 |
ECG 150 3/2
ECG 150 3/2 |
|
Width
|
101.6±2cm
121.9±2cm
152.4±2.54cm
182.9±2.54cm |
40±0.75inch
48±0.75inch
60±1inch
72±1inch |
|
Thickness |
0.6±0.06mm |
0.024±0.002inch |
|
Weight
|
600±30 g/㎡ |
17.7±0.9oz/yd2 |
|
Thread
Count |
Warp
Weft |
15±1.5per cm
15±1.5per cm |
38.1±3.8per inch
38.1±3.8per inch |
|
Tensile
strength
|
Warp
Weft |
6000 N/5cm
5000 N/5cm |
666 Ibs/inch
555Ibs/inch |
|
L.O.I% |
1.0% |
|
Service Temperature |
550℃ |
It is used in equipment,plant,car,thermal insulation and heat
preservation for pipeline.   |
|
|
|
|
